GR.2 Titanium Plates
Product Details:
- Product Name Stainless Steel Products
- Steel Type Stainless Steel
- Steel Product Type Steel Plates
- Shape Plate
- Surface Smooth
- Application Construction
- Color Silver
- Supply Ability : 200000 Kilograms Per Month
- Click to view more
X
Price And Quantity
- 100 Kilograms
Product Specifications
- Construction
- Silver
- Stainless Steel Products
- Plate
- Smooth
- Steel Plates
- Stainless Steel
Trade Information
- Cash Advance (CA)
- 200000 Kilograms Per Month
- 7-10 Days
- All India
Product Description
GR.2 Titanium Plates are commercially pure titanium grade material plates that are highly resistant to corrosion formation in different environments, such as chlorides, seawater, and acids. They are usually utilized in the applications that need great strength-to-weight ratio, superior corrosion resistance, and excellent bio-compatibility, such as medical implants, chemical processing, and aerospace. The plates feature ideal rectangular shape and thickness, and are the best suited to be utilized in the fabrication of fabrication of equipment for diverse industries. Further, GR.2 Titanium Plates offer super strength, and are available in different thicknesses, and finishes, so as to meet varied applications requirement.
TITANIUM GR. 2 SHEETS, PLATES & COILS SPECIFICATIONS
| Grade | Titanium Gr. 2, UNS R50400 |
| Standard | ASTM B265 / ASME SB265 |
| Thickness | 0.1mm To 30 mm |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard, etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Coils, Slatting Coils, Perforated Coils |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Titanium Gr. 2 | 3.7035 | R50400 | - | - | - | - | - |
TITANIUM GR. 2 SHEETS, PLATES & COILS CHEMICAL COMPOSITION
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | - | - |
TITANIUM GR. 2 SHEETS, PLATES & COILS MECHANICAL PROPERTIES
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 oC (3030 oF) | Psi - 49900 , MPa - 344 | Psi - 39900 , MPa - 275 | 20 % |
OTHER TYPES OF TITANIUM GR. 2 SHEETS, PLATES & COILS
| Titanium Gr. 2 Sheets, Plates & Coils | ASTM B265 Ti Gr. 2 Sheets | UNS R50400 Sheets, Plates & Coils |
| Titanium Gr. 2 Coils | Titanium Gr. 2 Plates | Titanium Gr. 2 Sheets |
| ASME SB265 Ti Gr. 2 Perforated Coils | Titanium Gr. 2 Slatting Coils | Titanium Alloy Gr 2 Sheets |
| UNS R50400 Titanium Gr. 2 Coils | WNR. 3.7035 Titanium Gr. 2 Sheets, Plates | UNS R50400 Titanium Gr. 2 Perforated Coils |
| Titanium Gr. 2 Slatting Coils | DIN 3.7035 Titanium Gr. 2 Sheets, Coils | ASTM B265 Ti Gr. 2 Sheets, Plates & Coils |
